Frigga®V5 (C) Pro Kit Real-time Gateway Solution

Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

V5(C) PRO KIT, the latest real-time gateway solutions from Frigga, offers unmatched long range, high penetration, and low power consumption that are critical for the modern supply chain.

V5(C) PRO KIT is tuned for consumers network with a large number of sensors communicating over long distance. It is suitable for large cold storage warehouses, refrigerated trucks and containers delivery, vaccine transport and storage, etc.

Frigga® IoT Cloud Platform intergrates the data collection and communication process to digitize and automate your supply chain management, enabling informed decisions through real-time visibility and alarm mechanism to secure your shipments and reduce lost.

Key Features and Advantages

V5 (C) Pro Host:

Real-time communication with beacons, one gateway is able to work with 30+ beacons at the same time, cost-effective;

High accurate positioning technology on the road and ocean, location accuracy±10m;

NIST traceable sensors to monitor temperature, humidity, light , shock, tilt, location, motion, ETA/ETD, ensure 360° view of shipment conditions;

3-axis acceleration detection and analysis, with the range of 0-16G; 8-level shock detection and analysis;

3-axis tilt detection and analysis, Resolution 0.1°;

Real-time temperature monitoring from -30°C to +70°C;

Real-time alerts to receivers via Email, SMS, APP (Android and iOS);

Large local storage, keep recording and storing data in offline mode. Zero data loss;

Support remote parameter setting, modify alarm threshold, etc;

M1H Beacon:

Fast data transfer rate to gateway, superior communication range +150 meters (open space);

Support +20m communication range through obstructions, excellent penetration within buildings/containers;

Each beacon has a big LCD screen, easy to read data;

Each beacon functions as a individual data logger, which  transfers data to gateway to give real-time visibility to reviewers, but also supports downloading report through its USB cable, ensure zero data loss;

Large local storage, up to 120-day use time with one charge;

Beacons are able to monitor temperature (-30°C to +70°C), humidity, light and location;

Frigga® Cloud Platform

Frigga cloud platform provides full real-time supply chain visibility. The platform supports global use, and provides following services throughout the process:

Overview of shipment data from gateway and beacons in real-time

Large local storage of gateway and beacons Shipment ETA/ETD, trans-shipments data

Real-time temperature, humidity, light, shock, tilt,  acceleration and location

Real-time notifications and alarms

Long-term data storage

Comply with GSP/FDA

Available on mobile/PC

Multi-level user management


V5(C) Pro Host

M1H Beacon

Usage Type


Monitor Information

Temperature, Humidity, Light, Shock, Tilt, Acceleration, Location, Motion, ETA/ETD (Ocean Tracking)

Temperature, Humidity, Light, Location

Location Type

GPS, A-GPS, self-developed mixed LBS, Wi-Fi Position, Ocean Tracking

Based on nearby V5(C) Pro Host

Temp. Sensor

Internal Temperature Sensor (NIST Traceable)

Temp. Range

-30°C to +70°C ( -22°F to +158°F)

Temp. Accuracy Range

±0.5°C (-20°C to +40°C); ±1°C for other range

Humidity/Accuracy  Range

5%~95%RH, ±3%(20%~80%RH); ±5% for other range

Light Sensor Range

0~52,000 Lux, detect whether doors or cartons open

Tilt Resolution



Memory Capacity

Max 28,800 readings

17,280 readings


Global LTE 4G/5G, fallback 2G network.

Super bluetooth technology

Super bluetooth technology

SIM Card

Internal Embedded (Global Data Roaming)



Li-ion/ Non-lithium Battery Optional

CR2450 Coin battery

Shelf Time

12 Months

Use Time

Up to 10-60 days (Based on reporting interval, optional 120 Days )

Data Logging Interval

10/20/60 Min, settable via platform

10 Min

Data Reporting Interval

10 Min. (10/20/30/60 Min settable via platform)

10-60 Min

IP Rating



Get PDF report via USB2.0/ Frigga cloud platform/Frigga Track (Mobile App)


103 x 61.3 x 23 mm / 130g

112 x 47 x 14 mm / 55g


FCC, CE, RTCA/DO-160G, UN38.3, ROHS, WEEE, EN12830
